| No. |
Part nr. |
Description |
Add info. |
Qty. |
| 1 |
46514000007 |
Frame |
R25/2 |
1 |
| 2 |
51144034136 |
Identification plate |
|
1 |
|
S600z |
Vehicle identification plate sidecar |
LS200, TR500 (Spezial) |
1 |
| 3 |
07119916604 |
Round-head screw |
|
2 |
| 4 |
32722072125 |
Support for clutch cable |
R25 |
1 |
| 6 |
46534034150 |
Foot peg, front & rear |
|
4 |
| x |
46514034264.7 |
Passenger foot peg, folding |
black |
2 |
| x |
46514034264.3 |
Passenger foot peg, folding |
galvanized, Denfeld |
2 |
| 7 |
46711235428 |
Foot peg rubber, front & rear |
|
4 |
| 8 |
07119921626 |
Hex nut, flat |
M12x1.5 |
2 |
| 9 |
07119936246 |
Serrated washer |
J12.5 |
2 |
| 10 |
07119914615 |
Hex bolt |
M12x1.5x35 |
2 |
| 11 |
07119922081 |
Hex nut |
M8 |
4 |
| 12 |
07119936206 |
Serrated washer |
J8.4 |
4 |
| 13 |
07119913111 |
Hex bolt, lower right side |
M8 x 35 |
1 |
|
07119912490 |
Hex bolt, lower left side |
M8 x 40 |
1 |
| 14 |
07119914089 |
Hex bolt |
M8 x 70 |
2 |
| 15 |
11814034133 |
Engine bolt (upper) 200 mm |
R25, R25/2 |
1 |
|
11814034113 |
Engine bolt (lower) |
R25, R25/2 |
2 |
| 16 |
07119932131 |
Spring washer |
B12 |
4 |
| 17 |
07119922147 |
Hex nut |
M12x1.5 |
4 |
| 18 |
11814034117 |
Engine spacer |
R25, R25/2 |
2 |
| x |
61138060104 |
Rubber plug |
R25 - R25/3 |
1 |
