| No. |
Part nr. |
Description |
Add info. |
Qty. |
| x |
63128050012 |
Headlamp |
R25, R25/2 |
1 |
| 1 |
63128050128 |
Headlamp ring |
|
1 |
| 2 |
63128050154 |
Lamp lens |
R25 - R25/3 |
1 |
| 3 |
63121353623 |
Gasket ring |
|
1 |
| 4 |
63128050181 |
Reflector |
R25 - R25/3 |
1 |
| 5 |
63128048181 |
Clip for light bulb socket |
R25/2, R25/3 |
1 |
| 6 |
07119978006 |
Light bulb, bilux. 6V 35/35W |
R25 - R25/3 |
1 |
|
07119978006.12 |
Light bulb, bilux. 12V 35/35W |
R25 - R25/3 |
1 |
| 7 |
63128048179 |
Light bulb socket |
R25 - R25/3 |
1 |
| 8 |
07119978243.4 |
Light bulb 6V 4W, park light |
R25 - R25/3 |
1 |
|
07119978243.4H |
Light bulb 12V 4W, park light |
R25 - R25/3 |
1 |
|
07119978243.2 |
Light bulb 6V 2W, neutral & charge |
|
1 |
|
07119978243.2H |
Light bulb 12V 2W, neutral & charge |
|
1 |
| 9 |
63128050160 |
Reflector clip |
|
6 |
| 10 |
63128050185 |
Screw M5x18 |
|
1 |
| 11 |
62148048154 |
Fuse holder in headlamp |
|
1 |
| 12 |
x |
Gasket ring |
|
1 |
| 13 |
62148048135 |
Fuse 8 Amp. |
|
1 |
| 14 |
x |
Gasket ring |
|
1 |
| 16 |
61318050136 |
Rubber washer |
|
4 |
| 17 |
61138050138 |
Rubber grommet |
|
2 |
| 18 |
63128071754 |
Rubber grommet speedo cable |
|
1 |
| 19 |
61318050134 |
Washer |
|
2 |
| 20 |
07119913661 |
Hex bolt, chrome |
M8x30, SSt |
2 |
| 21 |
61318070199 |
Rubber grommet |
|
1 |
| 22 |
61318070199.7 |
Rubber stop |
|
1 |
| 23 |
61138070196 |
Rubber grommet |
|
1 |
| 24,25 |
62148048135.K |
Lens with chrome ring, charge light |
|
11 |
| 26 |
61328048117 |
Key, metal |
R25, R25/2 |
1 |
|
61328048119 |
Key, metal |
R25/3 |
1 |
| 27 |
61328048111 |
Key (short version) |
R24 |
1 |
|
61328048116 |
Key (short version) |
R25, R25/2 |
1 |
| 28 |
63121353487 |
Neutral light fixture, green |
R24, R25/2 |
1 |
| 29 |
62148048126 |
Gasket |
R24, R25/2 |
1 |
| 30 |
61328048176.7 |
Mounting crown for switch plate |
R25, R25/2 |
1 |
| x |
61318070197 |
Rubber grommet for dimmer switch |
R24, R25 |
1 |
| x |
71609024031 |
Protection guard for headlamp |
chrome |
1 |
