| No. | Part nr. | Description | Add info. | Qty. |
|---|---|---|---|---|
| 1 | 63268054111 | Tail light, complete | 1 | |
| 2 | 63248054118 | Tail light, housing only | 1 | |
| 3 | 07119936110 | Serrated washer | J5.3 | 4 |
| 07119933060 | Spring washer | B5 | 4 | |
| 4 | 07119913227 | Hex bolt | M5x12 | 4 |
| 5 | 13112088552 | Rubber grommet | 1 | |
| 6 | 13720043809 | Rubber profile | 1 | |
| 7 | 63268054121 | License plate window | 1 | |
| 8 | 07119978220 | Light bulb (6 or 12V) | 5W | 1 |
| 9 | 63248054130 | Lamp carrier | 1 | |
| 10 | 63248054131 | Spring | 1 | |
| 11 | 63248654131 | Light bulb (6 or 12 V) | 21/5W | 1 |
| 12 | 63248054127 | Clip | 4 | |
| 13 | 63248054133 | Reflector | 1 | |
| 14 | 63248054123 | Rubber gasket ring | 1 | |
| 15 | 63248054135 | Lens | 1 | |
| 16 | 63248054125 | Chrome ring | 1 | |
| 12-16 | 63248054134 | Set | 1 | |
| x | 71609024111 | Protective bracket, chrome | R27 | 1 |
| x | 61128054170 | Cable harness in rear fender | 1 |
