No. |
Part nr. |
Description |
Add info. |
Qty. |
1 |
11241338150 |
Connecting rod |
|
2 |
2 |
07119981722 |
Grooved ball bearing 16007 C3 |
R50/5 - R100R |
1 |
3 |
11241254819 |
Dowel pin |
|
4 |
4 |
11111250155 |
Bush bearing (rot) |
R50/5 - R100R |
2 |
|
11111254788 |
Bush bearing (rot) |
R50/5 - R100R |
2 |
|
11111254789 |
Bush bearing (0.50 rot) |
R50/5 - R100R |
2 |
|
11111255288 |
Bush bearing (0.75 rot) |
R50/5 - R100R |
2 |
|
11111255285 |
Bush bearing (std. blau) |
R50/5 - R100R |
2 |
|
11111255286 |
Bush bearing (0.25 blau) |
R50/5 - R100R |
2 |
|
11111255287 |
Bush bearing (0.50 blau) |
R50/5 - R100R |
2 |
|
11111255289 |
Bush bearing (0.75 blau) |
R50/5 - R100R |
2 |
|
11111265437 |
Bush bearing (grün) |
R50/5 - R100R |
2 |
|
11111337724 |
Bush bearing (0.25 grün) |
R50/5 - R100R |
2 |
|
11111337614 |
Bush bearing (gelb) |
R50/5 - R100R |
2 |
|
11111337725 |
Bush bearing (0.25 gelb) |
R50/5 - R100R |
2 |
5 |
07119951480 |
Woodruff key 5x6.5 |
|
2 |
6 |
11241258460 |
Bearing shell |
R50/5 - R100RS |
4 |
|
11241258419 |
Bearing shell (+0.25) |
R50/5 - R100RS |
4 |
|
11241258420 |
Bearing shell (+0.50) |
R50/5 - R100RS |
4 |
|
11241258421 |
Bearing shell (+0.75) |
R50/5 - R100RS |
4 |
7 |
11111338342 |
Shaft seal 100x80x10 |
R50/5 - R100R |
1 |
8 |
11111256973 |
Stop ring (2.483 - 2.53) red |
|
2 |
|
11111256974 |
Stop ring (2.53 - 2.578) blue |
|
2 |
|
11111256975 |
Stop ring (2.578 - 2.626) green |
|
2 |
|
11111256976 |
Stop ring (2.626 - 2.673) yellow |
|
2 |
9 |
11241337553 |
Bolt for conrod |
R50/5 - R100RS |
4 |
10 |
11240618100 |
Connecting rod bush (small end) |
|
2 |
11 |
11221337099 |
Gasket ring |
R60/6, R75/6, R90/6, R90S |
2 |
12 |
11221256966 |
Flywheel M10x1 |
R50/5 - R90S <09-1975 |
1 |
|
11221262070 |
Flywheel M11x1.5 |
R60/6 -R100R >09-1975 |
1 |
13 |
11220016759 |
Hex bolt M10x1 - 24mm |
R50/5, R60/5, R75/5 |
5 |
|
11221257796 |
Hex bolt M10x1 - 32mm |
R60/6- R90S <09-1975 |
5 |
|
11221262060 |
Hex bolt M11x1.5 |
R60/6 -R100R >09-1975 |
5 |
14 |
11211250198 |
Sprocket |
R50/5 - R100 <09-1978 |
1 |
15 |
11211338172 |
Crankshaft M10x1 |
R50/5 - R90S <09-1975 |
1 |
|
11211338171 |
Crankshaft M11x1.5 |
R60/6 - R100R >09-1975 |
1 |
