No. |
Part nr. |
Description |
Add info. |
Qty. |
x |
80120021001 |
Cylinder head overhaul |
|
|
1 |
11121336872 |
Washer - 3.5 mm |
R50/5 - R100 |
4 |
2 |
11111263903 |
Hex nut SW15 |
R50/5 - R100 |
4 |
3 |
11121744332 |
Lock Ring |
R50/5 - R100R |
4 |
4 |
07129908142 |
Stud bolt |
R50/5 - R100RS |
4 |
5 |
11121250232 |
Protection tube Ø 16 mm |
R50/5 - R90S <09-1975 |
4 |
|
11121262259 |
Protection tube Ø 18 mm |
>09-1975 |
4 |
6 |
11121261775 |
Hex nut |
R50/5 - R90S <09-1975 |
8 |
|
11127650402 |
Hex nut M10 SW15 |
R60/7, R75/7 |
8 |
7 |
11121261773 |
Support for rocker arm shaft |
R60/6 - R90S >09-1975 |
8 |
|
11121258264 |
Support for rocker arm shaft |
R60/6 - R100RS >09-1975 |
8 |
8 |
11121254840 |
Spacer |
R50/5 - R75/5 02-'70 - 08-'72 |
8 |
9 |
11111460391 |
O-ring 15x21x2,5 |
<08-1970 |
8 |
|
11121255167 |
O-ring 15x21x3 |
02-1970 - 08-1972 |
8 |
10 |
11121254839 |
Sleeve |
R50/5 - R90S <09-1975 |
8 |
11 |
11121261405 |
Bushing |
R60/6 - R100RS >09-1975 |
8 |
12 |
07119941470 |
Roll pin 5x60 mm |
R50/5 - R80GS |
8 |
13 |
07119932099 |
Wave washer |
B6 |
8 |
14 |
07119905543 |
Hex nut |
M6 |
4 |
15 |
11121338426 |
Gasket |
R50/5 - R100RS |
2 |
16 |
11121250240 |
Cylinder head cover |
R50/5 - R100R |
2 |
17 |
07129908104 |
Stud bolt M6x40 |
R50/5 - R100R |
4 |
18 |
07119932090 |
Wave washer B8 |
|
2 |
19 |
11121744330 |
Cap nut - chrome |
|
2 |
|
11120023160.4 |
Cap nut - SSt polished |
R50/5 - R100 |
2 |
20 |
11121251598 |
socket-screw |
R50/5, R60/5/6/7 |
2 |
|
11121257396 |
socket-screw 25 mm length |
R75/5, R90/6 |
2 |
|
11121250227 |
socket-screw Ø 36, 30mm length |
R75/5 |
2 |
21 |
11121254126 |
Valve Seat Ring Intake +0.2 mm |
R50/5 |
2 |
|
11121256020 |
Valve Seat Ring Intake +0.4 mm |
R50/5 |
2 |
|
11120021750 |
Valve Seat Ring Intake +0.2 mm |
R60/5 |
2 |
|
11120021751 |
Valve Seat Ring Intake +0.4 mm |
R60/5 |
2 |
|
11121251253 |
Valve Seat Ring Intake +0.6 mm |
R60/5 |
2 |
|
11121256004 |
Valve Seat Ring Intake +0.2 mm |
R75/5 - R90S |
2 |
|
11121256006 |
Valve Seat Ring Intake +0.4 mm |
R75/5 - R90S |
2 |
22 |
11121337894 |
Valve Seat Ring exhaust +0.2 mm |
R50/5 |
2 |
|
11121337895 |
Valve Seat Ring exhaust +0.4 mm |
R50/5 |
2 |
|
11121338346 |
Valve Seat Ring exhaust +0.2 mm |
R60/5/6/7 |
2 |
|
11121338347 |
Valve Seat Ring exhaust +0.4 mm |
R60/5/6/7 |
2 |
|
11121337899 |
Valve Seat Ring exhaust +0.2 mm |
R75/5/6/7 |
2 |
|
11121337900 |
Valve Seat Ring exhaust +0.4 mm |
R75/5/6/7 |
2 |
23 |
11121338708 |
Valve guide 14.06 - 14.16 |
R50/5 - R100GS |
4 |
|
11121338711 |
Valve guide 14.25 - 15.90 |
R50/5 - R100GS |
4 |
24 |
11121338716 |
Cylinder head gasket |
R50/5 - R90S, R45 - R80R |
2 |
25 |
11121253158 |
Cylinderhead left |
R50/5 |
1 |
|
11121253155 |
Cylinderhead right |
R50/5 |
1 |
|
11121262960 |
Cylinderhead left |
R60/5, R60/6 |
1 |
|
11121262954 |
Cylinderhead right |
R60/5, R60/6 |
1 |
|
11121250224 |
Cylinderhead left |
R75/5, R75/6 <1976 |
1 |
|
11121250221 |
Cylinderhead right |
R75/5, R75/6 <1976 |
1 |
|
11121337869 |
Cylinderhead left |
R75/6 - R80RT <06-1987 |
1 |
|
11121337870 |
Cylinderhead right |
R75/6 - R80RT <06-1987 |
1 |
|
11121262964 |
Cylinderhead left |
R90/6 >09-1975 |
1 |
|
11121262968 |
Cylinderhead right |
R90/6 >09-1975 |
1 |
|
11121262854 |
Cylinderhead left |
R90S |
1 |
|
11121262852 |
Cylinderhead right |
R90S |
1 |
