| No. |
Part nr. |
Description |
Add info. |
Qty. |
| 1 |
23111006242 |
Covering plate |
|
1 |
| 2 |
07119934090 |
Circlip A17 x 1 |
|
1 |
| 3 |
07119981416 |
Ball bearing 6303 C3 |
C3 Clearance |
1 |
| 4 |
23211020102 |
Washer |
|
1 |
| 5 |
23221030266 |
Bushing 4th gear |
|
1 |
| 6 |
23221030153 |
Spur gear 4th speed |
|
1 |
| 7 |
23221040104 |
Stop washer |
|
2 |
| 8 |
23311030140 |
SIiding claw |
|
1 |
| 9 |
23211030100 |
Snap ring |
|
1 |
| 10 |
23221030262 |
Bushing 2nd & 3rd gear |
|
1 |
| 11 |
07119951461 |
Woodruff key 4x6,5 |
|
1 |
| 12 |
23221030150 |
Spur gear 3rd speed (24T) |
R50, R60 |
1 |
|
23221030154 |
Spur gear 3rd speed (24T) |
R50/2, R50S, R60/2, R69, R69S |
1 |
| 13 |
23221030146 |
Spur gear 2nd speed (28T) |
R50, R60 |
1 |
|
23221030147 |
Spur gear 2nd speed (27T) |
R50/2, R50S, R60/2, R69, R69S |
1 |
| 14 |
23211030104 |
Stop washer |
|
1 |
| 15 |
07119934171 |
Snap ring |
|
1 |
| 16 |
23311030140 |
SIiding claw |
|
1 |
| 17 |
23221030242 |
Spur gear 1st speed (33T) |
R50, R60 |
1 |
|
23221030246 |
Spur gear 1st speed (31T) |
R50/2, R50S, R60/2, R69, R69S |
1 |
| 18 |
23221030259 |
Bushing 1st gear |
|
1 |
| 19 |
23211030112 |
Stop washer |
|
1 |
| 20 |
07119981219 |
Ball bearing 6204 C3 |
C3 Clearance |
1 |
| 21 |
23211231651 |
Shim |
0.20 mm - 1.00 mm |
1 |
| 22 |
23211030027 |
Drive shaft, taper 1:5, M14x1.5 |
R50, R60 |
1 |
|
23211030028 |
Drive shaft, taper 1:6, M16x1.5 |
R50/2, R50S, R60/2, R69, R69S |
1 |
| X |
23211030168 |
Spring washer Ø 14mm |
R50, R60 |
1 |
|
23211030169 |
Spring washer Ø 16mm |
R50/2, R50S, R60/2, R69, R69S |
|
|
23211030120 |
Round nut M14 x 1.5 |
R50, R60 |
1 |
|
23211030122 |
Round nut M16 x 1.5 |
R50/2, R50S, R60/2, R69, R69S |
1 |
