| No. |
Part nr. |
Description |
Add info. |
Qty. |
| 1 |
34112060130 |
Brake lining, incl. rivets |
R25, R25/2 |
2 |
|
34112060132 |
Brake lining, incl. rivets |
R25/3 |
2 |
| 2 |
07119949213 |
Rivets |
3x10 mm |
16 |
| 3 |
34112060100 |
Brake shoe |
R25, R25/2 |
2 |
|
34112060103 |
Brake shoe |
R25/3 |
2 |
| 4 |
34112060134 |
Spring |
|
2 |
| 5 |
34113060104 |
Brake spanner |
R25, R25/2 |
1 |
|
34113060103 |
Brake spanner |
R25/3 - Ø 14 mm |
1 |
| 6 |
34212060107 |
Washer |
|
1 |
| 7 |
34213060108 |
Brake lever |
R25, R25/2 |
1 |
|
34213060111 |
Brake lever |
R25/3 |
1 |
| 8 |
07119936227 |
Serrated washer |
J10.5 |
2 |
| 9 |
07119922121 |
Hex nut |
M10x1 |
1 |
|
07129922436 |
Hex nut, self locking |
M10x1 |
1 |
|
07119922094 |
Hex nut |
M8x1 |
1 |
| 10 |
07119945111 |
Split pin |
2x20 mm |
1 |
| 11 |
|
|
|
|
| 12 |
34214044129 |
Pin for brake rod |
|
1 |
| 13 |
|
|
|
|
| 14 |
35214044145 |
Leaf spring |
R25/2, R25/3 |
1 |
| 15 |
35214044123 |
Brake rod |
R25 |
1 |
|
35214044124.4 |
Brake rod, w. brake light switch |
R25/2, R25/3 |
1 |
|
35214044124.2 |
Brake rod, w/o brake light switch |
R25/2, R25/3 |
1 |
| 16 |
07119931651 |
Disc for brake rod |
R25/3 |
1 |
| 17 |
34214044137 |
Spring |
|
1 |
| 18 |
34214044133 |
Barrel |
|
1 |
| 19 |
34214044141 |
Bushing |
|
1 |
| 20 |
34214044115 |
Wing nut |
|
1 |
| 21 |
36314038133 |
Grease nipple |
|
1 |
| 22 |
35214044009 |
Brake pedal |
w. bearing pin |
1 |
| 23 |
35214044009.A |
Bearing pin |
|
1 |
|
35214044009.B |
Bearing pin |
+0.5 mm |
1 |
| 24 |
35214044125 |
Spring for brake pedal |
|
1 |
| 25 |
34214044003 |
Brake lever |
|
1 |
